20W/30W/50W JPT Mopa M8 Fiber Laser Marking Machine Black Marking Table Type Supports Multiple Air-Cooled Raycus Galvo

The cabinet-type fiber laser marking machine offers precise and simple marking positioning, with a large working surface that allows for continuous marking over a wide range. It features an integrated design, low power consumption, long lifespan, and high efficiency.Fiber laser marking machines are widely used in integrated circuit chips, computer accessories,industrial bearings, cocks and watches, electronic and communication products,aerospace components, all kinds of auto parts,household appliances, hardware tools, dies, wire and cable, food packaging, jewelry, tobacco, and many fields such as military things graphics and text markup, mass production line and homework.

Classification:

Fiber laser marking machine

E-Mail: jwdevin@chinajwlaser.com

Product Details

Product Description

20W/30W/50W JPT Mopa M8 Fiber Laser Marking Machine Black Marking Table Type Supports Multiple Air-Cooled Raycus Galvo

*Product Parameters*
Laser source(optional)	Raycus / Max / JPT
Laser power(optional)	20w / 30w / 50w
Marking range(optional)	100100mm/150150mm/200200mm/250250mm/300*300mm
Engraving materials	Metal and Some Plastics
Marking speed	≤8000mm/s
Laser wavelength	1064nm
Minimum line width	0.01mm
Engraving depth	0.1-3mm
Character height	0.2mm
Repeat accuracy	0.002mm
Power demand	220V/50Hz/2A
Electricity power	<500W
Control system	Bejing JCZ
Control software	EZCAD

Packaging & Shipping

1.The delivery lead time would be 2-7 working days after receiving the payment.
2.As for the wholesalers/distributors, we could send the cargo by air, by sea or by railways via reliable forward.

Packaging details	Standard export packing, major products using export plywood case packing, small products use thick carton packing, ensure that the product packaging integrity and safety.
Shipping methods	1.Shipping by sea(recommend big product or a lot of goods of the order)
	2.By air
	3.By express: EMS, DHL, Fedex, UPS etc
