20 watts laser marking machine for metal hard plastic
Classification:
Product Details
20 watts laser marking machine for metal hard plastic
Product details
1.The optical fiber laser marking machine uses the laser beam to mark the surface of varioussubstances
permanently.
2.The marking effect is to show the deep material through the evaporation of thesurface material, or to "carve"
the trace through the chemical and physical changes of the surface material caused by the light.
3.or to burn part of the material by the light, showing all kinds of patterns, characters, barcodes and other
graphics that need to be etched.
1. Widely used in integrated circuit chips, computer accessories, industrial bearings, clocks and watches, electronic and communication products.
2. Aerospace components, all kinds of auto parts, household appliances, hardware tools, dies, wire and cable, food packaging, jewelry, tobacco, and many fields .
3. Military things graphics and text markup, mass production line and homework.
Model |
JW-F10w/20w/30w/50w |
Laser power |
10W/20W/30W/50W |
Laser Wavelength |
1064±10nm |
Q-frequency |
20KHz~100KHz |
Divergence |
0.3mard |
Marking range |
110*110mm/200*200mm/300*300mm |
Minimum line width |
0.01mm |
Minimum character |
0.1mm |
Marking speed |
7000mm/s |
Marking depth |
0 ~1mm |
Engraving line speed |
≤7000mm/s |
Repeatability accuracy |
±0.001mm |
Beam quality |
M2:1.2~1.8 |
Graphic format supported |
bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc. |
working voltage |
220V±10%/50Hz/4A110v60HZ |
Unit power |
0.5kw |
Working environment |
Clean and dust free or dust less |
Working (Humidity) |
5%-95% |
Accessories
Company Information
Liaocheng Dongchangfu jingwei Equipment Co., Ltd.
1.which located in Liaocheng City,Shandong Province, China. It was established in2010. With years’ development,now we grow up to be a professional factory which owns the complete system of R&D,manufacturing, sales and service integration.
2.We are now specializing in manufacturing laser engraving cutting machine, desktop laser stampengraving machine, fiber laser marking machine,laser tube, liner guide seat, laser heads, workingplatform for laser machine, and WD series engraving and cutting machines under outstanding quality.
3.We are looking forward to building long-term business relationships with customers both in the domestic and overseas , and we sincerely welcome more friends to contact for cooperation.
.
